Solar off-grid system
Key attributes Industry-specific attributes Solar Panel Type Monocrystalline Silicon Controller Type MPPT Other attributes Free installation service NO Place of Origin GUANGZHOU, China Load Power (W) 20kw, 10KW, Others Pre-sales project design Y Brand Name YIYANG Model Number JH-V9-OFF Application Home Battery Type Lithium Ion Mounting Type Ground /Roof Mounting Output Voltage (V) 110V/120V/220V/230V/240V Output Frequency 50/60HZ Work Time (h) 24Hours Product name Off-Grid Solar System Type Solar Home Energy Power System Solar panel Mono Solar Panel Battery LiFePO4 Lithium Battery Inverter Pure Sine Wave Inverter Controller MPPT Solar Charge Controller Mounting Structure Ground /Roof Mounting Function Provide Power Protection Overloads PV Cable 4mm2/6mm2Product Description Product Paramenters System Typle JH-5KW-OFF JH-8KW-OFF JH-10KW-OFF PV System Size Nominal (kWp) 5.28kw 8.8kw 10.56kw PV Module Specifications (half cell mono) Power (W) 440w Vmp (V) 32V Dimensions (L x W x H) (mm) 1723*1134*35mm Number of PV Modules 12 20 24 Certification IEC 61215,IEC 61730,UL 61730 ISO9001: 2015:ISO TUV/CE/CB/CQC Inverter Specifications Inverter Size (kW) 5kw 8kw 10kw Max DC Power (W) 7500w 12000w 15000w Max DC Voltage (V) 1000Vd.c. MPPT Voltage Range(V) 150---850Vd.c. Norminal Output Voltage 230/400V Certificates and Approvals NRS97,G98/G99,EN50549-1,C10/C11,AS 4777,VDE-AR-N4105,VDE0126,EC62040, 1EC62109-1,IEC62109-2 Dimension(W/H/D) 588*426*250mm Degree of protection IP65 Battery Bank Specifications Battery Type Lithium-iron phosphate (LiFePO4) Battery Bank Power(kWh) 10.24kwh 17.92kwh 20.48kwh Operating Voltage Range 172.8V--224.64V 302.4V--393.12V 345.6V--449.28V Recommend charge current 10~25A Life cycle 6000 times @80%DOD Remark: Please contact customer service for specific system parameters. System Typle JH-12KW-OFF JH-15KW-OFF JH-20KW-OFF PV System Size Nominal (kWp) 12.32kw 15.84kw 20.24kw PV Module Specifications (half cell mono) Power (W) 440w Vmp (V) 32V Dimensions (L x W x H) (mm) 1723*1134*35mm Number of PV Modules 28 36 46 Certification IEC 61215,IEC 61730,UL 61730 ISO9001: 2015:ISO TUV/CE/CB/CQC Inverter Specifications Inverter Size (kW) 12kw 15kw 20kw Max DC Power (W) 18000w 22500w 30000w Max DC Voltage (V) 1000Vd.c. MPPT Voltage Range(V) 150---850Vd.c. Norminal Output Voltage 230/400V Certificates and Approvals NRS97,G98/G99,EN50549-1,C10/C11,AS 4777,VDE-AR-N4105,VDE0126,EC62040, 1EC62109-1,IEC62109-2 Dimension(W/H/D) 588*426*250mm Degree of protection IP65 Battery Bank Specifications Battery Type Lithium-iron phosphate (LiFePO4) Battery Bank Power(kWh) 25.6kwh 30.72kwh ------ Operating Voltage Range 432V--561.6V 259.2V--350.4V -------- Recommend charge current 10~25A Life cycle 6000 times @80%DOD Remark: Please contact customer service for specific system parameters. Product Details Solar Panels > 30 years Warranty > Highest conversion efficiency of 22.52% > Anti-reflective and anti-soiling surface power, loss from dirt and dust> Excellent mechanical load resistance> PID Resistant,High salt and ammonia resistance PV Combiner Box >DC 1000V>Lightening Arrester>DC Breaker, Fuse, SPD inside>IP65 Protection Grade Hybrid Solar Inverter >All in one hybrid inverter >Seamless on/off grid transfer>Programmable working mode>Supports remote control of DG>Doubled capacity by paralleling 2 units Household Energy Storage > Deep cycle long lifespan > High discharge performance>Easy installation and Maintenance-free> Agm/Gel/LiFePO4/Lithium Ion Battery Type>12V/48V/51.2V High Voltage Battery > More than 6000 times, up to 90% DOD> Wide suitability of ambient temperature range Mounting Structure >Ground Solar Mounting system >Residential Roof(Pitched Roof)>Car parking solar mounting system >Vertical wall solar mounting system>Commercial Roof(Flat roof & workshop roof)>All aluminum structure solar mounting system PV Cable&MC4 Connector >MC4 Connector>PV Cable&MC4 Connector;>4mm2,6mm2,10mm2,16mm2, 25mm2, 35mm2 >Colors: Black For STD, Red Optional.>Lifetime: 25 Years.
